Long Stroke Air Brake Chamber Type 3030

$0.00/each

Long Stroke Air Brake Chamber Type 3030

Longest Side 24.02 in.
Median Side 9.96 in.
Shortest Side 8.86 in.
Weight 24.06 lbs.

Please Call +1 (416)-877-7478

SKU: TX-TR3030CLS Categories: , Tag:

Description

Long Stroke Air Brake Chamber Type 3030

– Superior Power Spring Technology; Advanced powder coating process; Resists corrosion and fatigue
– Double O-ring Centerseal; Two o-rings for positive sealing and plastic bearings for long life
– World Class Diaphragm; High quality rubber compound, resistant to heat and cold
– Rugged Service Housing; 9 gauge steel, powder coated
– Self-piloting Dust Shield
– Sizes to fit all drum brake applications

Actuator Type Size: 3030
Stroke Type: Long
Available Stroke: 3″, 76mm
Length from mounting bracket to end of Spring Housing: 9-7/8″, 251mm
Length of Piggyback: 7-3/8″, 187mm
Dimension at rolled Spring Housing flange: 8-5/16″, 211mm
Dimension at Service Clampband: 10-3/16″
Pushrod Length from face of Service Housing: 14″
Weight:  21.8 lbs. , 9.9 kg.

Additional information

Automann

179.SB3030SL

Bendix

NT3030ELS80, NT3030ELS99

Haldex

GC3030L, LC3030L, GC3030LR

Midland

3030054, MBI GC3030LR

Watson and Chalin

12963
